Product Structure
The Properties Of Surface Material
| MATERIAL NAME | 50# Bright White PET (TW - 050) |
| ARTICLE CHARACTER | PET |
| BASIC WEIGHT | 0.050±0.005 mm |
| FIXED AMOUNT | 70±5 |
| THE MOLD SLICES FUNCTION | Good die - cutting performance |
| PRINTING FUNCTION | Good printability |
| COLOR | Bright white |
| BAR CODE | Bar code performance: OK |
| SMOOTHNESS | Good smoothness |
| WEATHER RESISTANCE | Good weather resistance |
| TEMPERATURE RANGE | - 20 - 149℃ |
| SURFACE ENERGY | 38D↑ |
| DIAPHANEITY | Opaque |
| ELECTROPLATE STRENGTH | — — |
The Properties Of Acrylic Pressure-Sensitive Adhesive
| ADHESIVE | Pressure - sensitive adhesive (ZXPQN - 73) |
| ADHESIVE BASE | Solvent - based adhesive |
| BASIC WEIGHT | 0.040±0.002 mm |
| FIXED AMOUNT | 20±2 g/ |
| TACK | 3 ↑ |
| COHESION FORCE | 24 ↑ |
| STAINLESS STEEL ADHESION | 20 ↑ |
| PP ADHESION | — |
| GLASS ADHESION | — |
| RE - ADHESIDUAL | — |
| SERVICE TEMPERATURE RANGE | 120℃ |
| TEMPERATURE RANGE | -20 - 120℃ |
The Properties Of Liner
| MATERIAL NAME | 80g White Glassine (102) |
| ARTICLE CHARACTER | Semi - transparent release paper |
| BASIC WEIGHT | 0.060±0.007 mm |
| FIXED AMOUNT | 80±5 g/ |
| LINER RELEASE | 10 ↓ |
| DIE CUTTING | Good |
| PRINTING FUNCTION | — |
| SMOOTHNESS | Good |
| COLOR | White and semi - transparent |
| STORAGE | The shelf life is three years at 23°C and 50% humidity. |
| TESTING STANDARDS | Adhesion (N/in): GB/T2792-1998 Initial adhesion (#): GB/T4852-2002 Holding force (H): GB/T4851-1998 |
