B-472G
GAOFE
Our PP tire labels are specially developed for use on tire treads, ensuring reliable adhesion on rough and curved rubber surfaces. Featuring a white, glossy polypropylene face material and a strong hotmelt rubber-based adhesive, these labels stick firmly and remain readable throughout the supply chain. They are suitable for flexographic, screen, and thermal transfer printing, making them ideal for displaying tire and manufacturer information clearly and durably.
Face Material Characteristics:Glossy BOPP film (45 g/m²) offers soil resistance and supports flexographic, offset, and selective thermal transfer printing.
Adhesive Performance:Hotmelt adhesive (RHOT type) delivers strong permanent adhesion (35 N/25mm), functioning in extreme temperatures from -20°C to 50°C.
Liner and Eco-Certification:Pure wood-free kraft liner (87 g/m²) is FSC™ certified (SGSCH-COC-004879), ensuring a sustainable supply chain.
Overall Performance & Storage:Total thickness of 190 μm balances strength and conformability, with a 24-month shelf life under 20–25°C and 40–50% RH storage.
Tire treads labeling during manufacturing and distribution.
Identifying tire brands, models, and specifications.
Barcodes and tracking information for tires in warehouses and stores.
Suitable for tire factories, distributors, and retailers.
Optimal Printing Solutions
1.Recommended Ribbons:
Resin Thermal Transfer Ribbons
Model:TR4032B Resin Ribbon
Features:Achieves ≥1.7 OD print density on PP, PET, PE, and PVC surfaces.
Resists 100+ rubs, 80+ abrasions, and 20+ solvent exposures.
12-month shelf life; requires clean labels and 1–2 second drying post-print.
2.Recommended Printers:
Model:Zebra ZT610 Printer
Features:Supports 600 DPI resolution (23.62 dots/mm), suitable for printing fine barcodes, small texts and graphics.
It can handle labels as short as 0.125 inches in rewind mode.
Expandable 4GB SD Storage supports large label formats and complex print jobs.
Other Option
No. | Type | Model |
1 | Tire adhesive coated paper labels | B-470G |
Specification
Surface material | Syntyre |
Adhesive | Strong permanent |
Minimum labeling temperature | 10℃ |
Use lowest temperature | -20℃ |
Maximum operating temperature | 50℃ |
Surface material weight | 45g/㎡ |
Surface material thickness | 60um |
Adhesive Tack | 35 N/25mm |
Bottom paper | White woodfree kraft backing paper |
Bottom paper weight | 87g/㎡ ISO536 |
Thickness of Bottom paper | 82um ISO534 |
