VS800P
GAOFE
The VS800P Smart Code Reader is designed for industrial automation, offering exceptional compactness, high-speed performance, and precise reading capabilities. With innovative features such as liquid lens technology, Cube A autofocus, and a TUNE button for easy configuration, the VS800P is built to handle complex and dynamic environments, perfect for narrow spaces and demanding industrial applications.
With its wide reading range, high speed, high resolution, and exceptional clarity, it enables fast and accurate code reading even in dynamic and complex environments. Ideal for lithium battery, 3C electronics, pharmaceutical, and automated production lines.
Compact Design, Ideal for Narrow Environments
Compact size to fit into tight spaces, making it perfect for use in narrow or confined industrial environments.
Wide Reading Range, Flexible Distance
Equipped with dual-focus lenses (6mm/16mm) to cover a broad reading range of 40–400mm.
6mm lens: short-range (40–300mm) for small components and close-up inspection.
16mm lens: mid-to-long range (100–400mm) for larger materials and conveyor belt applications.
Liquid Lens Technology & Smart Auto-Focus
Liquid lens technology enables quick focus adjustments, while SmartMore’s Cube A autofocus algorithm ensures fast and accurate focus changes in varying conditions.
High Speed, Real-Time Capture
Supports up to 60fps frame rate, ensuring real-time capture of fast-moving products on production lines and preventing missed reads.
High Resolution, Clear Details
Delivers 1288×1088 pixel resolution with 3μm×3μm pixel size, enabling precise reading of tiny DataMatrix and barcodes, even on small electronic components.
TUNE Button for One-Click Parameter Adjustment
The TUNE button allows for one-click automatic parameter adjustment, significantly reducing on-site debugging time and ensuring optimal performance with minimal effort.
Dual Light Sources for Complex Scenarios
Offers red and white dual light sources, providing polarization capabilities to effectively handle complex scanning scenarios, such as highly reflective surfaces or items with intricate labels.
M12-17P Aviation Plug for Easy Connectivity
M12-17P aviation plug design enables single cable connection, simplifying the wiring process and ensuring stable, secure connections.
Global Shutter, Distortion-Free Imaging
Global shutter technology eliminates motion blur and distortion, producing stable and accurate images even in high-speed scenarios.
Adjustable exposure (20μs~1s) adapts to strong or weak lighting conditions to maintain image clarity.
Smart Auto-Focus, Consistent Clarity
Integrated liquid lens and Cube A auto-focus algorithm deliver millisecond-level focus adjustment, adapting quickly to varying distances without manual intervention.
✅ Lithium battery production lines: fast barcode reading and improved inspection efficiency.
✅ 3C electronics manufacturing: precise detection of tiny DataMatrix codes on components.
✅ Automated production lines: stable reading of barcodes at different heights and speeds.
✅ Pharmaceutical & packaging: accurate and quick reading of QR codes on bottles, boxes, and labels.
Other Option
| No. | Type | Model |
| 1 | 2D Barcode Scanner Fixed-Mount Barcode Reader | FM430 |
| 2 | VS1000 Reader | VS1000 |
Specification
